Tree view showing full hierarchy

Question

Hi everyone,
Thanks in advance for helping.
I am new to tree views and trying to get a simple hierarchy (from the account dimension) to show as a tree view. Part of the structure is shown in the screenshot below:

I'm using the following Dashboard Data Set Business Rule that I run using a data adapter linked to my tree view:
If args.DataSetName.XFEqualsIgnoreCase("TreeView")
	'Declare the account dimPK
	Dim DimPk As DimPk = BRApi.Finance.Dim.GetDimPk(si, "actAccount")
	'Declare the parent ID + member
	Dim parentMbrId As Integer = BRApi.Finance.Members.GetMemberId(si, dimTypeId.Account, "CF_000000")
	Dim parentMbr As Member = BRApi.Finance.Members.GetMember(si, dimTypeId.Account, parentMbrId)
	'Declare the child list of the parent
	Dim childList As List(Of Member) = BRApi.Finance.Members.GetChildren(si, DimPk, ParentMbrId)
	'Dim the new XFTreeItem List + properties
	Dim treeChildren As New List(Of XFTreeItem)
	Dim textColour As String = XFColors.Black.Name
	Dim imageSource As String = XFImageFileSourceType.ClientImage
	Dim imageName As String = XFClientImageTypes.StatusGrayBall.Name
	Dim isBold As Boolean = False
	Dim isEnabled As Boolean = True
	Dim isSelected As Boolean = False
	Dim isExpanded As Boolean = True
	'Loop through the children
	For Each child As Member In childList
		treeChildren.Add( _
			New XFTreeItem( child.Name, child.NameAndDescription, textColour, _
				isBold, isEnabled, isSelected, isExpanded, imageSource, imageName, _
				child.Name, Nothing))
	Next child

'Add the children to the parent
	Dim treeCollection As New XFTreeItemCollection
	treeCollection.TreeItems.Add( _
		New XFTreeItem( parentMbr.Name, parentMbr.NameAndDescription, textColour, _
			isBold, isEnabled, isSelected, isExpanded, imageSource, imageName, _
			parentMbr.name, treeChildren))
	Return treeCollection.CreateDataSet(si)
End If

I know the code is far from done. However, the output is currently looking like this:

Can someone help me with getting the next 'layers' of the hierarchy in place? Under CF_100000 etc?
Any help is appreciated!
Thanks a lot.
Floris

DanielWillis · Accepted Answer

I like to use recursive functions for things like this. Not sure if there is a more out of the box way as I haven't done a lot with treeviews.

I asked AI to turn your code into a recursive function. No idea if it works but it might set you on the path.

Sub BuildTree(ByVal si As SessionInfo, ByVal DimPk As DimPk, ByVal parentMbrId As Integer, ByVal parentMbrName As String, ByVal parentMbrDescription As String, ByVal textColour As String, ByVal imageSource As String, ByVal imageName As String, ByVal isBold As Boolean, ByVal isEnabled As Boolean, ByVal isSelected As Boolean, ByVal isExpanded As Boolean, ByVal treeCollection As XFTreeItemCollection)
    'Declare the child list of the parent
    Dim childList As List(Of Member) = BRApi.Finance.Members.GetChildren(si, DimPk, parentMbrId)
    'Dim the new XFTreeItem List
    Dim treeChildren As New List(Of XFTreeItem)()

    'Loop through the children
    For Each child As Member In childList
        ' Recursively build children of children
        Dim childTreeCollection As New XFTreeItemCollection()
        BuildTree(si, DimPk, child.Id, child.Name, child.NameAndDescription, textColour, imageSource, imageName, isBold, isEnabled, isSelected, isExpanded, childTreeCollection)
        ' Create XFTreeItem for current child and add children to it
        Dim childTreeItem As New XFTreeItem(child.Name, child.NameAndDescription, textColour, isBold, isEnabled, isSelected, isExpanded, imageSource, imageName, child.Name, childTreeCollection)
        treeChildren.Add(childTreeItem)
    Next

    ' Add the children to the parent
    Dim parentTreeItem As New XFTreeItem(parentMbrName, parentMbrDescription, textColour, isBold, isEnabled, isSelected, isExpanded, imageSource, imageName, parentMbrName, treeChildren)
    treeCollection.TreeItems.Add(parentTreeItem)
End Sub

' Usage:
Dim DimPk As DimPk = BRApi.Finance.Dim.GetDimPk(si, "actAccount")
Dim parentMbrId As Integer = BRApi.Finance.Members.GetMemberId(si, dimTypeId.Account, "CF_000000")
Dim parentMbr As Member = BRApi.Finance.Members.GetMember(si, dimTypeId.Account, parentMbrId)
Dim textColour As String = XFColors.Black.Name
Dim imageSource As String = XFImageFileSourceType.ClientImage
Dim imageName As String = XFClientImageTypes.StatusGrayBall.Name
Dim isBold As Boolean = False
Dim isEnabled As Boolean = True
Dim isSelected As Boolean = False
Dim isExpanded As Boolean = True
Dim treeCollection As New XFTreeItemCollection()
BuildTree(si, DimPk, parentMbrId, parentMbr.Name, parentMbr.NameAndDescription, textColour, imageSource, imageName, isBold, isEnabled, isSelected, isExpanded, treeCollection)

sameburn · Answer

Hi FlorisvdPoel given your use case, you might want to consider using one of the no-code approaches to achieve the same e.g. using the Member Tree component with a Member Dialog parameter type?

I wrote a blog on this here that you might find useful. Otherwise you will need a recursive function to iterate through each level in your hierarchy as per advice from DanielWillis
